Description

DC Electrical Characteristics STC Power Rating 310W PTC Power Rating 280.4W 1 STC Power per unit of area 14.8W/ft2 (159.8W/m2) Peak Efficiency 15.98% Power Tolerances data not available Number of Cells 60 Nominal Voltage not applicable Imp 8.45A Vmp 36.7V Isc 8.8A Voc 46V NOCT 45°C Temp. Coefficient of Isc 0.04%/K Temp. Coefficient of Power -0.4%/K Temp. Coefficient of Voltage -0.143V/K Series Fuse Rating 15A Maximum System Voltage 600V
Mechanical Characteristics Type Monocrystalline Silicon Output Terminal Type Multicontact Connector Type 4 Output Cable Wire Gauge 12 AWG Output Cable Wire Type PV Wire Output Cable Wire Length 43.3in (1,100mm) Frame Color White Backsheet Color data not available Length 77in (1,956mm) Width 39.1in (992mm) Depth 1.8in (45mm) Weight 52.9lb (24kg) Installation Method Rack-Mounted
Warranty & Certifications 80% Power Output Warranty Period 25yrs 90% Power Output Warranty Period 12yrs Workmanship Warranty Period 10yrs UL 1703 Fire Classification data not available Compliances UL 1703 CSI Listed Yes California Solar Initiative (CSI) list of Eligible Modules
