Description

The SLP050-12 50 watt, 12 volt CSA-certified C1D2 solar panel from Solarland® is an exceptionally high-quality solar module that meets the rigorous testing standards set forth by CSA. Recognized and accepted world-wide in a wide range of industrial applications, this the absolute best PV module solution for your solar application.

Product Specifications

Product Identification

• ModelSLP050-12
• SeriesSLP C1D2
• ManufacturerSolarland®

Electrical

• Watts (STC)50 W
• Max Power Voltage (VMPP)18.64 V
• Max Power Current (IMPP)2.68 A
• Open Circuit Voltage (VOC)22.18 V
• Short Circuit Current (ISC)2.85 A
• Number of Cells36 (4X9)

Mechanical

• TypePoly-Crystalline
• Dimensions21.02 (534mm) x 26.57 (675mm) x 1.38 (35mm)
• Weight10.25lbs (4.65kg)
• FrameHeavy-duty anodized aluminum
• ConnectorJunction Box

Product Diagram(s)

Product Downloads

Solarland® Installation Manual
