Description
Dasol DS-A18-135 > 135 Watt Solar Panel
White Backsheet, Clear Aluminum Frame
|
Model
|
DS-A18-135
|
|
Series
|
DS-A18
|
|
Manufacturer
|
Dasol
|
Mechanical
|
Type
|
Poly
|
|
Dimensions
|
54.0″ x 28.0″ x 2.0″
|
|
Weight
|
24.0 lbs
|
|
Frame
|
Clear Anodized Aluminum
|
|
Connector
|
Junction Box
|
Electrical
|
Watts (STC)
|
135 W
|
|
Max Power Voltage (VMPP)
|
18 V
|
|
Max Power Current (IMPP)
|
7.5 A
|
|
Open Circuit Voltage (VOC)
|
22.3 V
|
|
Short Circuit Current (ISC)
|
8.18 A
|
|
Operation Temperature Range
|
-40° to 85°C
|
|
Maximum System Voltage
|
600 VDC
|
Documentation
|
Data Sheet
|
Dasol DS-A18-135
|
Warranty
- Product Warranty: 3 Years Limited Warranty
- Output Warranty: 80% in 25 years
