Description
Solarland USA SLP075-12 > 75W 12 Volt Solar Panel
Clear Frame,White Backsheet. 35mm Frame.
CSA Certified for Class 1 Div 2. Groups A, B, C & D, T3 Hazardous Environments
| Model | SLP075-12C1D2 |
| Product Code | 075011263 |
| Series |
Off Grid- C1D2 |
| Manufacturer | Solarland USA |
Mechanical
| Type | Polycrystalline |
| Dimensions | 30.47″ x 26.57″ x 1.38″ |
| Weight | 13.22 lbs |
| Frame | Anodized Aluminum Alloy |
| Connector | Junction Box |
Electrical
| Watts (STC) | 75 W |
| Max Power Voltage (VMPP) | 18.64 V |
| Max Power Current (IMPP) | 4.02 A |
| Open Circuit Voltage (VOC) | 22.18 V |
| Short Circuit Current (ISC) | 4.27 A |
| Max System Voltage (UL) | DC 600 V |
Detailed Information
These 75W 12V panels by Solarland have been certified by the CSA
Laborartory to meet UL1703 standards and are for use in Class 1,
Division 2 hazardous environments. These solar modules feature a 35mm frame as well as a Junction Box.
- Certified to UL1703 and cUL1703
- Certified for Hazardous Environments
- C1D2 – Class 1, Division 2
- Nominal 12V DC for standard output.
- Outstanding low-light performance.
- Heavy-duty 50 mm anodized frames.
- High transparent low-iron,tempered glass.
- Rugged design to withstand high wind pressure, hail and snow load.
- Aesthetic appearance.
